Audio-Technica Launches New Beamforming Ceiling Array Microphone

Beamforming
Audio-Technica's ATND1061 beamforming ceiling array microphone (Image credit: Audoi-Technica)

Audio-Technica (opens in new tab) is introducing the ATND1061 beamforming ceiling array microphone (opens in new tab), an ideal solution for conference rooms, boardrooms and meeting spaces from large to small. Designed in a familiar form factor (roughly the size of a wireless access point), the ATND1061 is easy to install, set up and operate. It may be used singly or in multiples (for larger meeting spaces) to capture every person speaking in a room with clear, natural audio that reduces distracting environmental sounds.

Room configuration, zone setup and other settings are handled through A-T's user-friendly Digital Microphone Manager (opens in new tab)software application. The ATND1061 has six individual output channels, which, collectively, can be configured with up to 32 user-defined microphone pickup zones, providing the flexibility to cover a wide variety of room sizes and meeting types. Across all the output channels, the microphone's 90-degree orthogonal beams are capable of focusing on a particular point in space, preventing the pickup of unwanted noise.

[Audio-Technica Updates Wireless Manager Software] (opens in new tab)

The ATND1061's proprietary voice activity detection (VAD) technology enables the microphone to discern between a voice and unwanted noises such as paper shuffling. For installations without external digital signal processing (DSP), the ATND1061 features powerful onboard DSP, including automix, acoustic echo cancellation (AEC), noise reduction, automatic gain control (AGC) and four-band EQ. Exclusion zones can be set to avoid known sources of unwanted noise (such as HVAC systems), helping to maximize the effectiveness of the built-in noise-reduction and automatic-mixing functions.

Coverage Zones, Priority Zones for Complete Custom Room Control

User defined "Coverage Zones" and "Priority Zones" allow complete custom room coverage and optimized signal flow. Output Channel 1 can be configured with 16 user-defined Coverage Zones, within which a meeting participant may be seated or move about while speaking. The beam will track and keep the microphone focused on the speaker's voice, minimizing any room noise. Only one of the 16 Coverage Zones can be open at a time with the microphone automatically selecting the zone with the strongest signal identified as speech. Coverage Zones can be helpful in picking up either nonpriority or unplanned participants. Output Channels 2-6 can be configured with 16 user-defined Priority Zones which receive priority over Coverage Zones. A maximum of five Priority Zones can be open at a time, with each open zone selecting the strongest signal identified as speech. Priority Zones can be helpful in providing priority for a room's known participant locations.

[Audio-Technica Debuts New Condenser Boundary Mics for Conferencing] (opens in new tab)

An IR remote is also included to allow users to quickly mute the microphone when a muting function is not available in the room configuration. The IR Remote can also be used to recall presets or toggle the Power Save Mode on and off.

Beamforming

Multiple mounting options for the Audio-Technica ATND1061 beamforming ceiling array microphone (Image credit: Audio-Technica)

The ATND1061 can be flush- or surface-mounted in a drop ceiling or hard ceiling, or mounted in open architecture spaces via a standard VESA mount. The unit's low-reflective white finish matches standard ceiling tiles in most environments. The ATND1061 is UL 2043 compliant for installation in plenum spaces. All mounts, safety wiring, mounting hardware, and accessories are included.

[Dorna Sports Looks to Future With Audio-Technica 8.0 Microphone Concept] (opens in new tab)

The Dante-enabled ATND1061DAN has two network ports, which can be configured to fit any installation requirement. In "Single Cable Mode," Dante audio and microphone control data are sent together over a single standard category cable. In "Split Mode," Dante audio and microphone control data are sent separately over two category cables. The ATND1061 is powered by network PoE.

QSC Collaboration Adds Q-SYS Compatibility

Plug-ins are available for popular control systems. Notably, through a strategic partnership with QSC, the ATND1061 is compatible with the Q-SYS audio, video and control platform.

[Audio-Technica Debuts BP28, BP28L Line+ Gradient Large Diaphragm Condenser Microphones] (opens in new tab)

"Q-SYS was built on an open, software-based platform giving users the unique ability to quickly and easily integrate third-party solutions with Q-SYS to help enhance audio, video and control capabilities required in high-value spaces such as meeting rooms, boardrooms and executive spaces," said Geno Zaharie, Principal Alliances & Ecosystem, QSC. "The collaboration with Audio-Technica not only enhances and extends the capabilities through our ecosystem partners, but also helps integrators minimize installation complexity and costs."
