d3 Media Servers Drive Visuals at Game of Thrones Live Concert Experience

d3 Media Servers Drive Visuals at Game of Thrones Live Concert Experience

Game of Thrones fans were given another outlet for their favorite show when the “Game of Thrones Live Concert Experience” played a 24-date arena tour across North America. The tour featured the show’s composer, Ramin Djawadi, conducting an 35-piece orchestra and choirs performing highlights from the score. The 360-degree stage was rich in visuals and dynamic movement; d3 media servers tracked automation and drove the display of video content from six seasons of HBO’s epic fantasy series.

The tour opened in Saint Paul, MN in February and wrapped up in Portland, OR in April. To mirror the television show, the stage design was made up of “Seven Kingdoms.” The main stage (King’s Landing), featured Djawadi, the orchestra and a choir. A runway, also for performers, was then linked to a second stage (Winterfell) on the other side of the arena, which also featured a choir. Four smaller stages were then used, each named after different locations from the Game of Thrones world. Massive LED screens were suspended above the stages; nesting octagonal screens that looked like inverted wedding cakes, moved up and down.

San Francisco-based, Lucid provided technical design consultation for the tour, including d3 programming, management, and system design. “It was an exciting new venture and quite unique,” said Nick Fletcher, director of Lucid. “The in-the-round stage symbolized the seven kingdoms of the show. There was a lot of automation tracked in d3 on the stage and lots of video content driven by d3. No other media servers could have done the dynamic mapping and automation tracking required for the show.”

Fletcher specified three d3 4x4pros with SDI VFC cards; one pure master and one output machine ran the show, while the third system served as an understudy. VER supplied the all equipment required, including the d3 servers. Ken Delvo from VER was the d3 operator for this project. Lucid also worked closely with SRae Productions, which provided the overall scenic and show design.

Fletcher teamed with Nashville-based Matt Geasey during preproduction at VER Los Angeles. “Matt took care of all the lighting previs, the modeling, and fixture profiles,” Fletcher said. “We merged MA 3D and d3 for unified lighting and video previs and programming before the show.”

Fletcher said the tour, “pushed the boundaries when it comes to touring systems—this was the first tour with an IT department! There were managed switches creating a 40-gigabit network linking every department, so that everyone had unified access to network protocals across departments, from every location. We had a unified communications system for talent and crew, also riding on the same network.

d3’s Multi Transport feature asynchronously drove the main show content and the streamers for the orchestra. “Since the orchestra was different for every city on the tour, having streamers, like a live scoring session, was key to first-time performers of the music,” Fletcher said.

The dynamic tracking masks that Lucid built in d3 were essential in preventing video from bleeding onto the concentric tiers of the octagonal screens. And d3 tracked the show’s live automation data.

Fletcher and his team used d3’s r14.2 in beta, working directly with the d3 developers to fine-tune new features and assure rock-solid performance. “We used Creative Sequencing on the timeline and a lot of advanced mapping to wrap the scenic design in video, largely consisting of footage from the TV series, as it was not built to be displayed on the scenic surfaces,” he noted. “Drew Findley and Dirk Saunders, the lead creatives, did an amazing job re-cutting the show footage for the tour.”

d3’s flexibility came into play with the show’s evolving design. “When the scenic design changed, we didn’t have to reformat all the content; we did it all in d3,” Fletcher said. “Absolutely no other media server could have reacted that quickly to making global changes.”

Fletcher said Lucid values its relationship with d3’s developers, who remained “in constant contact” during the tour. “We really put d3 through the wringer with a big show like this,” he said. “But we’re very proud of the results and the fans just loved it.”
